Feature of AVERMEDIA CL332-HN PCIE Capture Card

2 Channel HDMI 1080P 30FPS Video Capture

CL332-HN is a PCIe Gen2 x1 capture card equipped with a maximum input of 1920×1080@60fps and capturing resolution of 1920×1080@30fps. It has embedded audio inputs via standard HDMI connectors to ensure sturdy cable connection while the HDMI video source input supports astounding compressed video capture resolution of up to 1920×1080@60fps.

Along with AVerMedia proprietary SDK, CL332-HN can be easily and seamlessly integrated into various vertical applications that require superb video capture quality such as IP cam, broadcasting, surveillance, etc. With AVerMedias Windows and Linux driver support, clients are able to choose from a wide range of platforms according to their specic needs; this makes the CL332-HN the best choice for professional Full HD capturing applications.

Hardware H.264 Compression

The CL332-HN is equipped with an advanced built-in H.264 hardware encoder that enables the system to encode without impacting CPUs computing power while maintaining high quality video encoding. This feature balances the load and in turn increases systems reliability. As a result, the computer and its resources can focus on other important applications at hand.

Low Prole Design Capture Card

Suitable for small-footprint embedded platform. The low prole form factor design provides a better use of internal space by reducing cabling and allowing for flexible heat sink solution.

Hardware De-interlacing Video Technology

AVerMedia hardware-based video engine technology implements the most useful video processing functions such as deinterlacing and down scaling. This can signicantly reduce computing burdens on software and hardware and in turn allow the resources to focus on other important parts of the application.

Video-processing SDK Included

Industrial customers can develop vertical applications flexibly and efficiently by using a specifically designed SDK, with features such as device control, media capture, A/V processing, and more.

Specifications of AVERMEDIA CL332-HN PCIE Capture Card

Host Interface	PCIe Gen2 x1
Audio Interface	HDMI embedded audio
Audio Format	PCM
Audio Sampling Rate	32KHz, 44.1KHZ, 48KHz
Connector Type	Standard HDMI
Input Interface	HDMI
Video Format	YUY2(4:2:2), YV12 (4:2:0), RGB24
Color Depth	8-bit
Channel No.	2 Ch
Input Video Resolution & Frame Rate	1920x1080p@(24/25/30/50/60) fps 1920x1080i@(50/60) fps 1680x1050p@60 fps 1440x900p@60 fps 1360x768p@60 fps 1280x1024p@60 fps 1280x960p@60 fps 1280x768p@60 fps 1280x720p@(50/60) fps 1280x800p@60 fps 1152x864p@60 fps 1024x768p@60 fps 800x600p@60 fps 720x576p@50 fps 720x480p@60 fps 640x480p@60 fps
Record Video Resolution & Frame Rate	1920×1080 @(24/25/30) fps 1680×1050 @30 fps 1440×900 @30 fps 1360×768 @30 fps 1280×1024 @30 fps 1280×960 @30 fps 1280×800 @60 fps 1280×768 @60 fps 1280×720 @(50/60) fps 1152×864 @60 fps 1024×768 @60 fps 800×600 @60 fps 720×576 @50 fps 720×480 @60 fps 640×480 @60 fps
Encoding Mode	Hardware Encoding (H.264) / Software Encoding
Multi-Channel Support	Yes
Multi-Card Support	Yes
Supported OS	Windows 7/8.1/10 (32/64 bits)*
Form factor	Low Profile
Dimension (L x W)	135 x 68.78 mm
Power Consumption	5W
Operating Temperature	0C ~ 65C
Operating Humidity	5% – 80% Relative Humidity
Safety Certification	FCC / CE
Warranty	1 Year
Note	***Features, Price and Specifications are subject to change without notice.
